Three types of power systems for foaming equipment: pneumatic, electric and hydraulic

I. Pneumatic system: simple structure
Pneumatic system is powered by compressed air, simple structure, consists of air compressor, air tube, cylinder, etc. Easy maintenance, only need to check the air line sealing and filter.
The advantages are obvious in flammable and explosive environment, such as processing polyurethane foam, it will not produce electric sparks, which can reduce the safety hazards, but also reduce the maintenance cost.
However, the air can be compressed, the power output is unstable, which affects the quality of high-precision products; the air compressor runs noisily, and needs sound insulation treatment.
Second, the electric system: accurate and efficient
The electric system relies on the motor to provide power, through the controller to accurately regulate the speed and torque, to meet the requirements of high-precision production, such as to ensure the stability of the quality of automobile seat foam.
High working efficiency can reduce the product error, and the motor energy conversion efficiency is high, which can reduce energy consumption.
The level of intelligence is improved, which can monitor the operation data in real time and warn the failure in advance, but it is sensitive to the environment and needs to be dustproof and moisture-proof.
Third, the hydraulic system: large load protection
Hydraulic system with the help of hydraulic oil to transfer power, based on Pascal's law, can provide strong power, suitable for large load scenarios.
Like the refrigerator shell foam production, can provide hundreds of tons of clamping force fixed mold, low-speed operation when the power output is stable.
However, the maintenance requirements are high, the cleanliness of the hydraulic oil has a great impact on the equipment, which is easily damaged by impurities; the work produces a lot of heat, and large equipment needs a cooling system.
¨NBSP;
Fourth, synergy and development
Factories often use a combination of three systems to achieve complementary advantages, such as "electric mixing + hydraulic clamping + pneumatic auxiliary" mode, can improve production efficiency.
At the same time, the power system is developing towards environmental protection, such as the application of oil-free air compressors, energy-saving motors, and biodegradable hydraulic oil, which is both environmentally friendly and cost-saving.
In short, the three power systems have their own advantages and applicable scenarios, and will be continuously improved with the progress of technology to help the development of the foam products industry.
